Portable Process and Pressure Calibration Instruments
Time Electronics offer a range of portable process instruments for field and laboratory use. Products include temperature calibrators and simulators for RTD and PT100 applications, and loop instruments for field instrumentation testing of transmitters, transducers and sensors.
Also available is a series of pressure calibration equipment including pressure calibrators, pneumatic and hydraulic hand pumps and digital pressure gauges. Models are designed to be high precision, durable, and simple operation for use across industries.
-
1090 Portable Process Calibrator
- Measure/simulate thermocouples
- Measure/simulate PT100
- Measure/source (µV/mV/mA)
- Display in °C and °F
- Automatic CJC - selectable
- 10 point memory recall
- Process loops 4-20mA/0-50mA
-
1048 Voltage/Current/Loop Calibrator
- Source/measure current & voltage
- 3 Source ranges to 22mA or 22V
- 3 Measure ranges to 70mA or 50V
- Transmitter simulator/sink
- Output steps and ramps
- Fine adjustment (inching)
- Accuracy 0.02% of span
-
1049 PT100 Simulator
- -200°C to + 800°C
- ± 0.3°C accuracy
- Based on ITS 90 EN60751
- 23 set points
- Exceeds class A
- Good temperature stability
- Passive resistance source
-
1077 Milliamp Transducer Simulator
- 3 operating modes
- 100mA source and load
- 24V line mode
- 0.02% accuracy
- Safety terminals
- Battery level indicator
- Supplied with protective cover
-
7000 RTD Temperature Calibrator
- 0.05°C accuracy, 0.01°C resolution
- 0.03Ω accuracy, 0.01Ω resolution
- 2, 3 and 4 wire connections
- Read and simulate °C, °F, °K, Ω
- Ramp and step
- PT100 plus 7 other RTD types
- User programmable
-
7005 Process Loop Calibrator
- Loop source/measure - V or I
- Measure 0 - 25V or 0 - 125mA
- Source 0 - 21V or 0 - 50mA
- Accuracy 0.01%
- Resolution 1μA or 1mV
- Programmable ranges
- Manual step, auto-step & ramp
-
7006 Loop Simulator & Source
- 4 - 20mA or 0 - 10V loops
- 7 calibration set-points
- Accuracy 0.1%
- TxSim and RxTest modes
- Autostep output - adjustable rate
- Battery powered PP3
- Internal loop drive supply
-
7007 Loop Signal Indicator
- 4 - 20mA, 0 -10V, 0 - 50V ranges
- LCD 4 digit display, mA, V, % of rng
- Accuracy 0.05%
- RxSim, TxTest, or 50mA/50V modes
- Internal loop supply, 25mA max
- Battery powered 9V PP3
- Supplied with carry case
-
7010 Single Channel Pressure Calibrator
- Vacuum to 600bar versions
- Accuracy 0.04% of full scale
- Pneumatic or hydraulic
- Over-pressure alarm
- Isolated 24/36V loop supply
- Loop current measure
- Mains / battery power
-
7015 Dual Channel Pressure Calibrator
- Vacuum to 600bar versions
- Accuracy 0.04% of full scale
- Pneumatic or hydraulic
- Over- pressure alarm
- Isolated 24/36V loop supply
- Loop current measure
- Mains / battery power
-
7016 Regulated Low Pressure Calibrator
- Regulated low pressure
- Vacuum to 10bar versions
- Accuracy 0.04% of full scale
- Pneumatic
- Isolated 24/36V loop supply
- Loop current measure
- Mains / battery power
-
7018 Differential Pressure Calibrator
- 0.2, 2, 5 & 10bar versions
- Accuracy 0.04% of full scale
- Pneumatic
- Over-pressure alarm
- Isolated 24/36V loop supply
- Loop current measure
- Mains or battery powered
-
7040 Digital Pressure/Current Calibrator
- Vacuum to 20bar versions
- 0.04% accuracy
- Loop current calibration
- 9 engineering units
- Min / Max function
- Leak rate function
- RS-232 serial interface
-
7050 Multifunction Process Calibrator
- Measure to 40V, 400mA, 40kΩ
- Output voltage up to 10V
- Output current to 20mA
- Output resistance to 40kΩ
- Accuracy 0.03% of range
- Thermocouple measure & simulate
- RTD measure & simulate: PT100
-
7078 Auto-Ranging Digital Pressure Gauge
- Vacuum to 200bar (3000psi)
- Accuracy 0.1% of reading
- 9 engineering units
- Silicone piezo resistive sensors
- Reads gauge & absolute pressure
- Easy to read backlit display
- Robust with protective rubber boot
-
7090 Handheld Pneumatic Pressure Calibration Pump
- Pressure to 40bar (600psi)
- Vacuum to -950mbar
- Oversized check valve
- Contoured cushioned handles
- Protective caging for vent valve
- Hose, fittings, & carry case supplied
- Optional digital gauges
-
7091 Digital Pressure Gauge
- Vacuum to 40bar (600psi)
- Accuracy 0.2% of full scale
- Easy-to-read display
- 5 digit resolution
- 3 times per second measure speed
- Analogue dial indicates % pressure
- Ideal for use with the 7090 pump
-
7093 Precision Loop and Dual Pressure Calibrator
- Vacuum to 600bar versions
- Pressure accuracy 0.04% of FS
- 0.025% high accuracy versions
- Pneumatic or hydraulic
- I measure: 125mA, Source: 50mA
- V measure: 25V, Source: 21V
- V/I accuracy 0.01%
-
7094 Digital Pressure Gauge
- 0 to 100bar (1500psi) pressure
- Accuracy 0.2% of full scale
- Easy-to-read display
- 5 digit resolution
- 3 times per second measure speed
- Analogue dial indicates % pressure
- Ideal for use with the 7194 pump
-
7095 Handheld Hydraulic Pressure Calibration Pump
- 0 to 700bar (10,000psi)
- Priming feature for fast air purge
- Oversized check valve
- Contoured cushioned handles
- Built-in pressure relief valve
- Hose, fittings, & carry case supplied
- Optional digital gauge
-
7096 Digital Pressure Gauge
- Pressure up to 700bar
- Accuracy 0.2% of full scale
- Up to 5000 hours battery life
- Easy-to-read display
- 5 digit resolution
- 3 times per second measure speed
- Ideal for use with the 7095 pump
-
7190 Benchtop Micro-Pressure Calibration Pump
- -0.4bar vacuum to 0.4bar (6psi)
- Double output manifold
- Resolution: 0.0001mbar (0.01Pa)
- Screw press for fine adjustment
- Bellows minimise leakage
- Isothermal chamber for stability
- Compact, lightweight design
-
7191 Benchtop Low Pressure Calibration Pump
- -0.95bar vacuum to 4bar (60psi)
- Double output manifold
- Resolution: 0.0001mbar (0.01Pa)
- Screw press for fine adjustment
- Bellows minimise leakage
- Isothermal chamber for stability
- Compact, lightweight design
-
7193 Benchtop Pneumatic Pressure Calibration Pump
- 0.95bar vacuum to 40bar (600psi)
- Pneumatic
- Double output manifold
- Ideal for use as gauge comparator
- High pressure resolution (0.1mbar)
- Screw press for fine adjustment
- Compact design ideal for field or lab
-
7194 Benchtop Pneumatic Pressure Calibration Pump
- 0.95bar vacuum to 140bar (2000psi)
- Double output manifold
- High pressure resolution
- High pressure stability
- Easy to use pressure lever/handle
- Free from humidity and dirt
- For reference calibration with gauge
-
7195 Benchtop Hydraulic Pressure Calibration Pump
- Vacuum to 700bar (10,000psi)
- Double output manifold
- High pressure resolution
- High pressure stability
- Smooth pressure generation
- Oil or deionized water
- For reference calibration with gauge
-
7198 Pressure Calibration Accessories Kit
- Adaptors/fittings/connectors/hoses
- Metric/BSP/parallel/NPT adaptors
- Coupling connectors
- Quick release & minimess hoses
- 10" adjustable spanner included
- Suitable for use with pumps
- Compact kit for labs & on-site work
-
TEG Digital Pressure Gauges
- Ranges to 2500bar (37500psi)
- 0.02, 0.05, 0.1, 0.2% FS accuracies
- Gauge/Absolute/Compound/Differential
- Unique self-protection capability
- 5 digit resolution
- Long working period & battery life
- 3 times per second measure speed
